ASUS PRIME B760M A WIFI DDR4 (Intel 13th Gen Motherboard)
SKU: 5643656D5434S57F5665s56555763
PRODUCT TYPE: Motherboards
Hurry! Only 0 Left in Stock!
Shipping within 4 to 5 working days in UAE
We are one of the highest-rated online shops in UAE
Your satisfaction is guaranteed with our 1-year warranty.
Socket: 1700 socket
For processors: Intel
Chipset: Intel B760
Memory type: DDR4 DIMM
Integrated graphics core: depending on the processor
WLAN (WiFi): Yes
Motherboard format: Micro-ATX
Memory type: DDR4 DIMM
Number of memory slots: 4
Maximum memory size [GB]: 128
Maximum operating memory frequency [MHz]: 5,333
Overclocking: Extreme Memory Profile
Connectors
Internal connectors: ARGB LED 5V (3x), ATX 8pin, ATX 24pin, COM, Fan (2x 4pin), Fan CPU (2x 4pin), LPT, M.2 PCI-E 4.0 (2x), RGB LED 12V (1x) , SATA 6Gb/s (4x), TPM, USB 2.0 (3x), USB 3.2 Gen 1 - Type C (1x), USB 3.2 Gen 1 (2x)
Rear connectors: 3.5mm jack (3x) 7.1CH, DisplayPort (1x), HDMI (2x), LAN 2.5Gb/s (1x), PS/2 (1x), USB 2.0 Type-A (4x), USB 3.2 Gen 2 Type-A (2x)
DisplayPort: Yes
HDMI: Yes
Controller
LAN Controller: Yes
USB 2.0 controller: Yes
USB 3.2 Gen1 controller: Yes
USB 3.2 Gen2 Controller: Yes
SATA 6 Gb/s controller: Yes
M.2 controller: Yes
Integrated technologies
WLAN (WiFi): Yes
WLAN (Wifi) standards: Wi-Fi 1 (802.11a), Wi-Fi 2 (802.11b), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) , Wi-Fi 6 (802.11ax)
Bluetooth: Yes
Integrated graphics core: depending on the processor
Bus
PCI-E 4.x: Yes
Number of PCI-Express x16 slots: 3
M.2 drive support: M.2 PCI-E 2242-80 (2x)
